The Difference Between: rasps, files and rifflers

Rasps, files, and rifflers are tools used for shaping and smoothing wood, each differing in construction and typical use.

A rasp has individually raised, coarse, cone-shaped teeth, making it the most aggressive of the three, designed to remove material quickly. It leaves a surface that is rougher compared to that left by a file. Rasps are available in various shapes, sizes, and coarseness grades, such as flat, half-round, and round. Cabinet rasps have a fine tooth pattern, wood rasps have coarser teeth and four-in-one (also called four-in-hand) rasps have different teeth patterns and shapes on each side.

A file, on the other hand, has low, tightly spaced rows of teeth cut into its surface. Straight-cut (also called single-cut) files have parallel rows of teeth, while cross-cut (also called double-cut) files have rows running at opposing angles, delivering a more aggressive cut. Although a file can be used on wood for more precise shaping and smoothing, it is typically used on metal since the teeth tend to clog quickly with wood fibers. Like rasps, files come in various shapes and sizes, including flat, round, half-round, triangular, and square.

Advertisement


A riffler has variously shaped cutting surfaces on both ends, with a handle in the middle. File-cut rifflers have long lines of teeth, while rasp-cut rifflers have pointy teeth. They are primarily used for shaping concave and convex surfaces. There are eight traditional styles available in different lengths, proportional to the coarseness of the cutting surfaces.

The Difference Between: volts, amp-hours and watt-hours

Most battery-powered hand tools use at least one of three battery packs: 18V (Volt) for standard power tools, 12V for compact and lower-power-demand tools, and 36V or higher for some outdoor gardening and landscaping tools. All battery packs are made up of individual battery cells. Each cell has a specific nominal voltage, typically 3.6V, which is the amount of power it produces. Three cells are wired together in series to make up a 12V battery pack, and five cells for an 18V pack.

Batteries have an amp-hour (Ah) capacity, depending on the density of the battery cells. The Ah is a measure of battery capacity, commonly referred to as the “run-time”—essentially how long the battery will produce power. It’s comparable to the size of the gas tank in a car: the larger the tank, the more gas it carries, and the farther the car can travel. Runtime will depend on the environment and the application in which the power tool is used. The more energy a battery can store, the longer the battery can run before it needs to be recharged—and the more work you can get done.

Another measure of battery capacity is the watt-hour (Wh), which represents the amount of energy (in watts) the battery can supply per hour. It’s comparable to the gas in a car’s gas tank. Watt-hours are determined by multiplying the battery voltage (V) by the amp-hour (Ah) rating. For example, an 18V battery with an 8.0 Ah rating supplies 144 nominal watt-hours of power, while an 18V battery with a 6.0 Ah rating would supply 108 watt-hours.

Advertisement


For more information read Next Generation Batteries: what manufacturers are doing to enhance user productivity

The Difference Between: rabbets, dados and grooves

Rabbets, dados, and grooves are basic forms of joinery that can be made by hand or machine. Essentially, they are types of butt joints, where end grain is joined to face grain. A rabbet (also called a rebate) is a cut made along the edge of a board, either with or across the grain, forming two sides at a 90º angle. A dado is a square or rectangular slot that runs across the grain, while a groove is a similar slot that runs with the grain.

Due to their similarities, dados and grooves are often referred to as “slots.” Both dados and grooves can extend the full width of a board or be stopped at one or both ends, in which case they essentially become mortises. A rabbet is cut on the end or edge (face) of a board, with or across the grain—the protruding piece is called the tongue. Rabbet joints are commonly used in simple box joinery, where joint strength is not critical, as well as for attaching cabinet backs and assembling drawers.

These joints can be cut by hand using tools such as a router plane, hand saw, chisel, and mallet, or with power tools like a table saw, handheld or table-mounted router, or track saw.

Advertisement


For a more detailed description of these joints read “Rabbets, dados and grooves“.
